ULTRASONIC FIBER ORIENTATION METER (SST-4000)
หมวดหมู่สินค้า: IDM Test
รหัส :
For the determination of fiber orientation. Includes TSI and TSO calculations. Electronic equipment, easy to use. Measurement in 4 seconds per position. Software for Windows. Possibility of having the equipment with automatic passage of the sheet to obtain profiles of the reels.
31 มกราคม 2568
ผู้ชม 10 ผู้ชม
ULTRASONIC FIBER ORIENTATION METER (SST-4000)
Cod: 280101
For the determination of fiber orientation. Includes TSI and TSO calculations. Electronic equipment, easy to use. Measurement in 4 seconds per position. Software for Windows. Possibility of having the equipment with automatic passage of the sheet to obtain profiles of the reels.
FEATURES:
- Original equipment for the determination of fiber orientation.
- Includes TSI and TSO calculations.
- Propagation distance: 120 mm.
- Measurement interval: 11,25º.
- Measuring range: 0.75-7.5 km/s.
- Repetitivity: ± 0.5º
- It includes automatic pin of samples FD-1.
- Includes PC software (not included). Easy-to-use electronic equipment.
- Measurement of the sample: 13 seconds.
- CE Marking
