BeVision D2
The BeVision D2 provides an efficient solution to the size and shape analysis of dry, high-flowability powders or granules. Tens of thousands of particles can be measured by a BeVision D2 within three minutes. Combining a high-speed camera with a precise telecentric lens, the BeVision D2 is able to efficiently analyze the size and shape of particles in the range of 30 - 10,000 μm.
Features and Benefits
● Measurement range: 30 - 10,000 µm
● 24 different particle size and shape parameters
● Reduction of workload and time
● Outstanding reproducibility
● Results in compliance with ISO 9276-6
● Fully automated operation
● Powerful software provides a comprehensive evaluation
● Comparable with sieving results
| BeVision D2 | |
| General | |
| Measuring principle | Dynamic image analysis method |
| Parameters | Particle size, shape, and number |
| Measurement performance | |
| Measuring range | 30 – 10,000 μm |
| Typical measurement time | 1 to 3 min * |
| Number of size / shape classes | 100 (user adjustable) |
| Special functions | SOP settings, automatic tests, analysis of saved images |
| Main device | |
| High-speed CCD camera | Up to 120 images per second |
| Light source | White LED stroboscopic parallel light source |
| System parameters | |
| Dimensions (L × W × H) | 61.0 × 35.0 × 44.0 cm |
| Weight | 26 kg |
| Supply voltage | 100 / 240 V, 50 / 60 Hz |
| Software | |
| Conformity | ISO 13322, ISO 9276 |
| Reports | Customizable reporting |
| * Sample and sample preparation dependent | |
