Digital Hook & Point Gauges
20 เมษายน 2566
ผู้ชม 188 ผู้ชม
DESCRIPTION
A range of digital hook and point gauges which includes a liquid crystal display which indicates the movement of the gauging rod.
A push button sets the display to zero at any position, allowing the measurement of movement relative to a datum.
A mounting plate is clamped to a suitable support structure and a flat vertical shaft retained by the gauging unit is free to slide up and down over the water surface.
A steel point or hook is attached to the bottom end of the shaft and is used to locate the water surface.
The gauging unit consists of a liquid crystal electronic display which indicates the movements of the shaft.
A quick-release mechanism permits large changes to be rapidly accommodated, and a screw adjustment is provided for accurate final positioning.
A push button sets the display to zero at any position, so that relative movements compared with a datum can be easily measured.
This gauge is easy to use and minimises potential errors resulting from reading vernier scales.
DEMONSTRATION CAPABILITIES
- Measurement of steady state of water with digital display
TECHNICAL SPECIFICATIONS
Ranges:
- H1-7: 300mm
- H1-8: 500mm
Resolution: ±0.01mm
Typical accuracy: ±0.03mm
Repeatability: ±0.01mm
Operating temperature range: 5ºC to 40ºC
