PI - Colortouch Module for On Line pulp color & brightness measurement
หมวดหมู่สินค้า: Techpap
รหัส : PI Color & Brightness
The color module complies to the iso & tappi standardized test methods for color measurements. Pulp inspector integrates a technidyne colortouch pc system, with all its functionnalities, and the benefits of a 24/7 automatic sampling, testing and data storage system.
01 กุมภาพันธ์ 2566
ผู้ชม 155 ผู้ชม
Brightness
The ColorTouch PC is in exact conformance with ISO 2469 and 2470 far the measurement of ISO Brightness.
Fluorescence
Samples may be measured under 4 different calibrated sources C (ISO Brightness), 065 (outdoor daylight), UVEX (no ultra violet energy), GanzGriesser. Plus 2 userdefined calibrated sources
ERIC 950 Measurement
Together with the Eric module in option Techpap has developped an Hyperwashing module to help DIP plants to forcast the deinkability of their pulp
Standards
Meets the following industry standards
- ISO Standards 2469, 2470, 2471, 3688, 5631, 9416,
- 11475, 11476, 12625, 22754, 22891
- TAPPI Optical Methods T519, T525, T527, T534, T560
- PAPTAC E.1, E.2, E.5, E.8
- ISO & TAPPI
- PULP INSPECTOR
